Mechanical Parameter
| Similar Mainframe Model Specifications (Product Size Selection Models) | |||||
| Type | DB-420 | DB-520 | DB-720 | DB-900 | DB-1200 |
Film Width | Max. 420 mm | Max. 520 mm | Max. 720 mm | Max. 900 mm | Max. 1200 mm |
Bag Length | 80-300 mm | 80-350 mm | 180-350 mm | 100-600 mm | 100-1000 mm |
Bag Width | 60-200 mm | 100-250 mm | 100-500 mm | 260-430 mm | 290-580 mm |
Film Roll Diameter | Max. 320 mm | Max. 320 mm | Max. 320 mm | Max. 400 mm | Max. 400 mm |
Packaging Rate | 5-60 Bags/Min | 5-60 Bags/Min | 5-55 Bags/Min | 5-20 Bags/Min | 5-20 Bags/Min |
Power | 220V 50/60 Hz, 2 kW | 220V 50/60 Hz, 3 kW | 220V 50/60 Hz, 3 kW | 220V 50/60 Hz, 4.5 kW | 220V 50/60 Hz, 5 kW |
Measurement Range | 150-1500 ml | 2000 ml | 4000 ml | 1-25 ml | 1.5-45 ml |
Film Thickness | 0.04-0.08 mm | 0.04-0.12 mm | 0.04-0.12 mm | 0.04-0.12 mm | 0.04-0.12 mm |
Machine Size (LxWxH) | 1217x1015x1343 mm | 1488x1080x1490 mm | 1780x1350x2050 mm | 2305x1686x2725 mm | 2900x2050x3500 mm |
Weight | About 650 KG | About 680 KG | About 750 KG | ||
Certification | CE/SGS/ISO Certification | ||||
A form fill and seal machine (FFS) is the backbone of efficient and reliable packaging operations, and DBAO Packaging Machinery delivers solutions that set new standards in performance. Our FFS machines are engineered to automate the entire packaging process—forming the bag, filling the product, and sealing it with precision—all in a single, streamlined workflow. This integration not only reduces manual labor but also enhances consistency, speed, and cost-effectiveness across diverse production lines.
Designed with advanced automation and durable engineering, DBAO’s form fill and seal machines are suitable for a wide range of products, including powders, liquids, granules, and solids. With flexible bag formats such as pillow bags, gusset bags, quad seals, zipper pouches, and stick packs, our systems allow manufacturers to meet varying packaging demands and market trends with ease.
Applications
DBAO’s form fill and seal machines are widely used in industries such as:
- Food & Beverage: Snacks, grains, coffee, sugar, frozen foods, sauces, and liquids.
- Pharmaceutical & Healthcare: Powders, supplements, medical granules, and sachets.
- Chemicals & Household Products: Detergents, cleaning powders, pesticides, and industrial goods.
- Pet Food & Agriculture: Dry pet food, seeds, and fertilizers.
Why Choose DBAO Packaging Machinery?
- Over 14 Years of Experience: Professional engineers providing tailored packaging solutions.
- Trusted Globally: More than 1,500 machines running in 70+ countries worldwide.
- Innovative Engineering: Compact yet powerful machines designed with third-generation technology.
- Comprehensive Equipment Line: Full packaging solutions, including supporting devices like check weighers, metal detectors, and labeling systems.
- Dedicated Customer Support: 24/7 technical service, spare parts availability, and reliable after-sales care.
