Mechanical Parameter
Type | DB-320 | DB-380 | DB-420 |
Film Width | Max. 320 mm | Max. 380 mm | Max. 420 mm |
Bag Length | 50–200 mm | 60–280 mm | 60–280 mm |
Bag Width | 50–150 mm | 60–180 mm | 60–180 mm |
Film Roll Diameter | Max. 320 mm | ||
Packaging Rate | 35–70 Bags/Min | 35–70 Bags/Min | 35–70 Bags/Min |
Power | 220V 50/60 Hz, 2.2 kW | 220V 50/60 Hz, 2.5 kW | 220V 50/60 Hz, 2.5 kW |
Range of Measurement | 50–500 ml | 50–750 ml | 100–1000 ml |
Packing Film Material | OPP/CPP, OPP/PE, BOPP/VEPET/PE, etc. | ||
Machine Size (L×W×H) | 700×580×1550 mm | 970×680×1950 mm | 970×720×1950 mm |
Weight | 250 kg | 300 kg | 400 kg |
Modern manufacturing requires packaging solutions that balance efficiency, precision, and flexibility. A vertical filling machine from DBAO Packaging Machinery is engineered to meet these demands by automating the entire filling and packaging process. Designed with advanced automation, these machines form the bag, accurately fill the product, and seal it securely in one continuous cycle, ensuring consistent results and reducing manual intervention.
What sets DBAO’s vertical filling machines apart is their ability to adapt to a wide range of packaging requirements. Whether you are handling powders, liquids, granules, or solid items, our machines provide precise dosing and reliable sealing to maintain product freshness and quality. The versatility extends to packaging formats as well—pillow bags, gusset bags, quad-seal bags, zipper pouches, and stick packs are all supported, giving manufacturers the freedom to serve multiple market segments with a single machine.
Key Features
- All-in-One Automation: Bag forming, precise filling, and sealing in one process.
- Versatile Packaging Options: Handles pillow, gusset, quad-seal, zipper, and stick bag styles.
- Precision Dosing: Suitable for powders, liquids, granules, and solids.
- Smart Control System: Panasonic PLC and servo technology for efficient and stable operation.
- Durable Construction: High-quality materials and components ensure long service life.
- Compact & User-Friendly: Easy to operate, integrate, and maintain.
Applications
DBAO vertical filling machines are ideal for a wide range of industries:
- Food & Beverage: Coffee, grains, nuts, sugar, snacks, sauces, frozen foods, and liquids.
- Pharmaceutical & Healthcare: Nutritional powders, medical sachets, supplements, and granules.
- Chemicals & Household Products: Detergents, pesticides, cleaning powders, and liquids.
- Pet Food & Agriculture: Dry and wet pet food, seeds, fertilizers, and animal feed.
