Mechanical Parameter
| Similar Mainframe Model Specifications (Product Size Selection Models) | |||||
| Type | DB-420 | DB-520 | DB-720 | DB-900 | DB-1200 |
Film Width | Max. 420 mm | Max. 520 mm | Max. 720 mm | Max. 900 mm | Max. 1200 mm |
Bag Length | 80-300 mm | 80-350 mm | 180-350 mm | 100-600 mm | 100-1000 mm |
Bag Width | 60-200 mm | 100-250 mm | 100-500 mm | 260-430 mm | 290-580 mm |
Film Roll Diameter | Max. 320 mm | Max. 320 mm | Max. 320 mm | Max. 400 mm | Max. 400 mm |
Packaging Rate | 5-60 Bags/Min | 5-60 Bags/Min | 5-55 Bags/Min | 5-20 Bags/Min | 5-20 Bags/Min |
Power | 220V 50/60 Hz, 2 kW | 220V 50/60 Hz, 3 kW | 220V 50/60 Hz, 3 kW | 220V 50/60 Hz, 4.5 kW | 220V 50/60 Hz, 5 kW |
Measurement Range | 150-1500 ml | 2000 ml | 4000 ml | 1-25 ml | 1.5-45 ml |
Film Thickness | 0.04-0.08 mm | 0.04-0.12 mm | 0.04-0.12 mm | 0.04-0.12 mm | 0.04-0.12 mm |
Machine Size (LxWxH) | 1217×1015×1343 mm | 1488×1080×1490 mm | 1780×1350×2050 mm | 2305×1686×2725 mm | 2900×2050×3500 mm |
Weight | About 650 KG | About 680 KG | About 750 KG | ||
Certification | CE/SGS/ISO Certification | ||||
In today’s competitive market, manufacturers need packaging solutions that deliver both speed and reliability while maintaining product integrity. DBAO’s vertical form fill and seal machines (VFFS) are designed to meet these exact demands, offering a fully automated process that transforms packaging efficiency from start to finish. With the ability to form bags, fill them with precise quantities, and seal them securely—all in one continuous operation—our VFFS systems provide a streamlined approach that reduces downtime and ensures consistent product quality.
What sets DBAO’s vertical form fill and seal machines apart is their ability to adapt to a wide range of packaging materials and product types. From powders and granules to liquids and solids, these machines are versatile enough to support industries with diverse requirements. Their high-speed servo-driven controls and PLC-based interface guarantee accurate portioning and sealing, while minimizing errors and waste.
Applications
DBAO’s vertical form fill and seal machines are suitable for:
- Food Industry – Snacks, cereals, coffee, sugar, sauces, and frozen products.
- Pharmaceuticals – Medical powders, capsules, tablets, and small-dose liquids.
- Chemicals – Fertilizers, detergents, and powdered chemicals.
- Agriculture – Seeds, animal feed, and agricultural supplements.
- Beverages – Liquid concentrates, dairy products, and flavored drinks.
Why Choose DBAO Packaging Machinery?
- Extensive Industry Experience – Over a decade of expertise in packaging automation.
- Tailored Engineering – Machines customized to meet unique production needs.
- Global Reliability – Trusted by clients across 70+ countries.
- Top-Quality Components – Equipped with internationally recognized electrical parts.
- Strong After-Sales Service – Ongoing technical support and spare parts availability.
- Proven Efficiency – Solutions designed to increase output and reduce packaging costs.
- Commitment to Innovation – Continuous upgrades to meet modern industry demands.
- Durability & Longevity – Equipment engineered for long-term industrial use.
