Mechanical Parameter
| Similar Mainframe Model Specifications (Product Size Selection Models) | |||||
| Type | DB-420 | DB-520 | DB-720 | DB-900 | DB-1200 |
Film Width | Max. 420 mm | Max. 520 mm | Max. 720 mm | Max. 900 mm | Max. 1200 mm |
Bag Length | 80-300 mm | 80-350 mm | 180-350 mm | 100-600 mm | 100-1000 mm |
Bag Width | 60-200 mm | 100-250 mm | 100-500 mm | 260-430 mm | 290-580 mm |
Film Roll Diameter | Max. 320 mm | Max. 320 mm | Max. 320 mm | Max. 400 mm | Max. 400 mm |
Packaging Rate | 5-60 Bags/Min | 5-60 Bags/Min | 5-55 Bags/Min | 5-20 Bags/Min | 5-20 Bags/Min |
Power | 220V 50/60 Hz, 2 kW | 220V 50/60 Hz, 3 kW | 220V 50/60 Hz, 3 kW | 220V 50/60 Hz, 4.5 kW | 220V 50/60 Hz, 5 kW |
Measurement Range | 150-1500 ml | 2000 ml | 4000 ml | 1-25 ml | 1.5-45 ml |
Film Thickness | 0.04-0.08 mm | 0.04-0.12 mm | 0.04-0.12 mm | 0.04-0.12 mm | 0.04-0.12 mm |
Machine Size (LxWxH) | 1217×1015×1343 mm | 1488×1080×1490 mm | 1780×1350×2050 mm | 2305×1686×2725 mm | 2900×2050×3500 mm |
Weight | About 650 KG | About 680 KG | About 750 KG | ||
Certification | CE/SGS/ISO Certification | ||||
The vertical form seal machine stands out as a packaging solution that combines speed, precision, and versatility, making it an essential asset for modern production lines. Unlike conventional systems, it is engineered to manage a wide variety of product types—from delicate powders and liquids to bulky granules and solids—while ensuring consistent seal integrity and high-quality finishes. This adaptability makes it a reliable choice for manufacturers seeking to expand product diversity without compromising efficiency.
One of its most notable advantages is efficiency. The machine operates at high speeds while maintaining exceptional accuracy in both filling and sealing, reducing downtime and minimizing product waste. Its advanced sealing technology ensures that every package is airtight, extending product shelf life and protecting contents from contamination. This is particularly valuable in industries such as food and pharmaceuticals, where product safety and quality are non-negotiable.
Key Features
- Advanced Sealing Technology: Ensures strong, airtight, and tamper-proof packaging for enhanced product safety.
- Flexible Packaging Options: Supports a wide range of bag styles and sizes, including pillow bags, gusseted bags, and flat-bottom pouches.
- High-Speed Operation: Optimized for rapid production cycles, reducing downtime and boosting throughput.
- Precision Control System: Integrated with a smart PLC and touch-screen panel for accurate adjustments and real-time monitoring.
- Durable Construction: Built with high-quality components to withstand continuous heavy-duty operations.
Applications
The vertical form seal machine is widely used across multiple industries, including:
- Food – Snacks, grains, sauces, powders, and frozen items.
- Pharmaceuticals – Tablets, powders, capsules, and liquid medicines.
- Cosmetics – Creams, lotions, shampoos, and masks.
- Chemicals – Powdered or liquid chemical products requiring safe, sealed packaging.
- Agriculture – Seeds, fertilizers, and pesticides.
